Product Archive

This product is discon­tinued and no longer available.
Please visit the following page of our current MCX cartridge series…

The MCX series…


Acoustic Signature

The MM Series has been engi­nee­red in accor­dance with the highest stan­dards and is con­gru­ent with our unre­len­ting commit­ment to pro­vi­ding the most precise and accu­rate repro­duc­tion possi­ble without colo­ration. The weight and size fit to the most com­mon turn­ta­bles on the market today. The MM Series pro­­vides excel­lent com­pati­bility when used in an assort­ment of play­back sys­tems and with a wide variety of phono preamps.

The Acoustic Signa­ture MM2 moving-magnet cart­ridge has an impro­ved engine, which provi­des an increa­sed output of 5.5 mV and an opti­mized sound repro­duc­tion and a high level of sonic accu­racy. It has a Nude Elliptical dia­mond and split pole pins with a cop­per wire. The MM2 adds more dyna­mics and reso­lution, sounds more open and repro­duces more details com­pa­red to the MM1 model.

Continue reading…
Close text…

Acoustic Signature MM2 cartridge side view

Special features:

  • Moving-magnet system
  • Improved engine with an increa­sed output of 5.5 mV
  • Nude elliptical stylus
  • Split pole pins with a copper wire
  • Excellent compa­tibility with most play­back systems

Acoustic Signature MM2 cartridge seen from the front

Acoustic Signature MM2 cartridge backside

Technical data

Cartridge system:Moving-magnet
Stylus type:Nude elliptical
Coil material:Copper
Voltage output
(at 1 kHz, 5 cm/sec.):
5.5 mV
Compliance, dynamic, lateral:20 m/mN
Recommended tracking force:1.8 g (18 mN)
Frequency range at -3 dB:20-25,000 Hz
Recommended load resistance:47 K
Recommended load capacitance:150-300 pF
Tracking ability at 315 Hz
(at recommended tracking force):
80 m
